In 2018 this car got back on the road after sitting in a garage for over 15 year. The Corrado was driven allot that year, but the PG/ABA turbo engine couldn’t live up to it’s expectations.
At the end of 2018 it was decided the engine had to go to and plans were soon made to fit new fully build 2.0 20VT stroker engine, together with track focused suspension parts, brakes and a 4-motion drivetrain.
The Corrado in 2018:
Specs (updated ’19 new engine)
Engine:
2.0L 06A AEG engine, 92,8 stroke
AEB 20vt big port cylinder head
Mamba GT2871R Ball Bearing Turbo
Compressor Housing A/R: .60 (5200 Cover)
Compressor Wheel : 53.1 mm / 71.0 mm / Trim 56 (11+0 GTX Billet Wheel w/ Extend Tip)
Mamba V-band in & out A/R .61 Turbine Housing
Turbine Wheel : 47 mm / 53.8 mm / Trim 76
GFB EX44 wastegate
Custom equal length sidewinder manifold
DP engine parts forged stroker pistons, 83mm, 9.5CR
ZRP 144*20mm H-Beam Connecting Rods
ARP 201-5001 main studs
King MB5566XP Main bearings
King CR4104XP Rod bearings
Gates GTS-T306RB performance timing belt
AGU intake with billet injector cups
Billet fuel rail
Holley fuel pressure regulator
Genesis II 500cc “FOGGER” injectors
Submerged 044 surge tank
Bosch 044 fuel pump
Bar-Tek high flow check valve (6AN)
AN6 PTFE nylon braided fuel lines with Torques.uk fittings
Silicone boost and coolant hoses
Mikalor t-bolt hose clamps
Forge fast road dumpvalve
Golf G60 intercooler
Green performance air filter
Vibra-Technics VAG600M motor mount
Vibra-Technics VAG606M Transmission mount
Custom stainless 3″ downpipe
Homebrew Group A exhaust system
Golf G60 radiator
Aluminum coolant flanges
Double slim radiator fans
Oem oil/water cooler delete
Mocal thermostatic oil sandwich plate
Motamec 19 row AN10 oil cooler
S-Max Oil Catch Can with Green Performance filter
Drivetrain:
Chromoly tubular front subframe and control arms
Chromoly tubular rear subframe and control arms
Passat B6 aluminum uprights (front and rear)
O2M DQB six speed gearbox
Gen 1 Haldex
Shortened Audi TT prop shaft
Electronics:
Ecumaster Black ecu
Audi R8 coil packs 06E905115F
Club level engine loom with Raychem DR-25 sleeving, Deutsch connectors
Bosch Motorsports DBW pedal 0280755051
Bosch Motorsports 76mm DBW throttle body 0280750474
MAC 35A-AAA-DDBA-1BA boost control solenoid
Auberins 5bar MAP sensor (1/8 NPT)
Auberins 10bar fuel pressure sensor (1/8 NPT)
Auberins 10bar oil pressure sensor (M10x1)
Odyssey PC680 Racing battery
Daihatsu 65A lightweight alternator
Interior
Sparco Pro2000 seats
Exterior:
EmpireGFX candy red taillight overlays
Carbon rain tray
Carbon lower windshield trim
Suspension/Brakes/Wheels:
Ohlins front dampers (Leon TCR)
H&R monotube rear dampers (Golf V GTI)
PMC motorsport topmounts
EHPS conversion (Mercedes A-class)
Porsche 996 F+R brakes
Audi RS4 330×22 rear brake discs
Mercedes 330×28 front brake discs
Tilton 600 series pedal box
AP Racing 0700 CP-2623-91 Master Cylinders
Hydraulic handbrake conversion kit (motorsport-tools)
Wilwood 0.625 hydraulic handbrake mastercylinder
Porsche 996 GT2 wheels (17″x 7J & 9J)
H&R DRM adapters 15mm back (ET 40)
Federal 595 RS 215-40-17 front
Federal 595 RS 215-45-17 rear
